Raise/Lower/Tilt Blinds + Glass For Doors

The Raise/Lower/Tilt (RLT) operator is available for door styles including sliding patio doors, French doors, or swinging glass entry doors.

• Custom 1" Sizes: 8"–80" wide x 14"–80" tall (in 1/16" increments)
• Custom 7/8" Sizes: 8"–48" wide x 18"–80" tall (in 1/16" increments)
• 6 colors (white, tan, sand, silver moon, slate gray, espresso)
• Tempered or annealed glass
• Clear glass, 8 Low-E (single or dual) options
• EasyGlide or SlimLine operator design* (raise/lower/tilt functions)
• Minimum order quantity = 1
• 10-year full warranty
• Child & pet-friendly: no exposed cords
• No dusting, maintenance-free: blinds are enclosed between glass
• Assembled in the USA

Blind Options

The Raise/Lower/Tilt (RLT) operator is available for door styles including sliding patio doors, French doors, or swinging glass entry doors.

• Custom 1" Sizes: 8"–80" wide x 14"–80" tall (in 1/16" increments)
• Custom 7/8" Sizes: 8"–48" wide x 18"–80" tall (in 1/16" increments)
• 6 colors (white, tan, sand, silver moon, slate gray, espresso)
• Tempered or annealed glass
• Clear glass, 8 Low-E (single or dual) options
• EasyGlide or SlimLine operator design* (raise/lower/tilt functions)
• Minimum order quantity = 1
• 10-year full warranty
• Child & pet-friendly: no exposed cords
• No dusting, maintenance-free: blinds are enclosed between glass
• Assembled in the USA

*1" IG's only. Available in white.

Specifications

	Blinds + Glass Classic	Blinds +  Glass Custom
IG panel sizes	14"–36" wide* 42"–80" tall* (*in 1/16" increments) 1" thick	8"–80" wide* 14"–80" tall* (*in 1/16" increments) 1" thick 8" - 48" wide* 18" - 80" tall* (*in 1/16" increments) 7/8" thick
Sq ft max	1": 17 sq ft	1": 17 sq ft (no more than 36" in one direction) 7/8": 18 sq ft (no more than 36" in one direction)
Glass types	1" Tempered: Up to 17 sq ft (dual operator)	1" Tempered: Up to 17 sq ft (dual operator above 12 sq ft) 1" Annealed: Up to 15 sq ft (single operator) 7/8" Tempered: Up to 18 sq ft (dual operator 48" and above) 7/8" Annealed: Up to 15 sq ft (single operator 48" and below)
Low-E options	1" Single: 270, 272, 340, 366 1" Dual: I89/270, I89/272, I89/340, I89/366	1" and 7/8" Single: 270, 272, 340, 366 1" and 7/8" Dual: I89/270, I89/272, I89/340, I89/366
NEAT options (Tempered Glass Only)	—	1" and 7/8" Single: 270, 366 1" and 7/8" Dual: I89/270, I89/366 (Tempered glass only)
Operator options	1" Classic design: 0.667" thick 1" Low-profile design: 0.438" thick	1" and 7/8" EasyGlide design: 0.539" thick 1" SlimLine design: 0.323" thick 1" High or low operator position* (*above 30" in height, single operator only)
Operator handing	1" Left- or right-hand operator	1" and 7/8" Left- or right-hand operator
Size Charts	1" Tempered glass	1" Tempered glass1" Annealed glass7/8" Tempered glass7/8" Annealed glass

Technical Information

Read more about:
Product Performance
Product Codes
Energy Efficiency & Thermal Performance
Safety Certifications
3-Part Specifications

Download design specifications:
Blinds + Glass Classic—Raise/Lower/Tilt
(1 MB) Adobe PDF
Blinds + Glass Custom—Raise/Lower/Tilt
(1.1 MB) Adobe PDF
Blinds + Glass 7/8" Custom
(2 MB) Adobe PDF
